温馨提示：因橡塑行情波动太大，线上价格未能及时更新，更多详情及技术问题请来电咨询(微信同号）
特性：加纤25%、热稳定性、耐水解，本色NC010色号，黑色BK099色号。
用途：机械、仪器仪表、汽车部件、电子电气、铁路、家电、通讯、纺机、体育休闲用品、油管、油箱及一些精密工程制品。
|
Rheological properties
|
dry / cond
|
Unit
|
Test Standard
|
|
Molding shrinkage, parallel
|
0.3 / *
|
%
|
ISO 294-4, 2577
|
|
Molding shrinkage, normal
|
1.1 / *
|
%
|
ISO 294-4, 2577
|
|
Mechanical properties
|
dry / cond
|
Unit
|
Test Standard
|
|
Tensile modulus
|
8500 / 6000
|
MPa
|
ISO 527-1/-2
|
|
Stress at break
|
180 / 120
|
MPa
|
ISO 527-1/-2
|
|
Strain at break
|
3 / 6
|
%
|
ISO 527-1/-2
|
|
Charpy impact strength, +23°C
|
60 / 80
|
kJ/m2
|
ISO 179/1eU
|
|
Charpy impact strength, -30°C
|
60 / 45
|
kJ/m2
|
ISO 179/1eU
|
|
Charpy notched impact strength, +23°C
|
10 / 11
|
kJ/m2
|
ISO 179/1eA
|
|
Charpy notched impact strength, -30°C
|
7 / 7
|
kJ/m2
|
ISO 179/1eA
|
|
Thermal properties
|
dry / cond
|
Unit
|
Test Standard
|
|
Melting temperature, 10°C/min
|
262 / *
|
°C
|
ISO 11357-1/-3
|
|
Glass transition temperature, 10°C/min
|
80 / *
|
°C
|
ISO 11357-1/-2
|
|
Temp. of deflection under load, 1.80 MPa
|
252 / *
|
°C
|
ISO 75-1/-2
|
|
Temp. of deflection under load, 0.45 MPa
|
261 / *
|
°C
|
ISO 75-1/-2
|
|
Vicat softening temperature, 50°C/h 50N
|
257 / *
|
°C
|
ISO 306
|
|
Coeff. of linear therm. expansion, parallel
|
33 / *
|
E-6/K
|
ISO 11359-1/-2
|
|
Coeff. of linear therm. expansion, normal
|
112 / *
|
E-6/K
|
ISO 11359-1/-2
|
|
Burning behavior at 1.5 mm nominal thickness
|
HB / *
|
class
|
IEC 60695-11-10
|
|
Thickness tested (1.5)
|
1.5 / *
|
mm
|
IEC 60695-11-10
|
|
Yellow Card available
|
Yes / *
|
-
|
-
|
|
Burning behavior at thickness h
|
HB / *
|
class
|
IEC 60695-11-10
|
|
Thickness tested (h)
|
3.0 / *
|
mm
|
IEC 60695-11-10
|
|
Yellow Card available
|
Yes / *
|
-
|
-
|
|
Burning rate, thickness 1 mm
|
26
|
mm/min
|
ISO 3795 (FMVSS 302)
|
|
FMVSS
|
B
|
-
|
ISO 3795 (FMVSS 302)
|
|
Electrical properties
|
dry / cond
|
Unit
|
Test Standard
|
|
Relative permittivity, 100Hz
|
3.6 / -
|
-
|
IEC 62631-2-1
|
|
Dissipation factor, 100Hz
|
70 / -
|
E-4
|
IEC 62631-2-1
|
|
Volume resistivity
|
1E13 / -
|
Ohm*m
|
IEC 62631-3-1
|
|
Surface resistivity
|
* / 1E13
|
Ohm
|
IEC 62631-3-2
|
|
Comparative tracking index
|
400 / -
|
-
|
IEC 60112
|
|
Other properties
|
dry / cond
|
Unit
|
Test Standard
|
|
Water absorption
|
6.4 / *
|
%
|
Sim. to ISO 62
|
|
Humidity absorption
|
2 / *
|
%
|
Sim. to ISO 62
|
|
Density
|
1320 / -
|
kg/m3
|
ISO 1183
|
|
Material specific properties
|
dry / cond
|
Unit
|
Test Standard
|
|
Viscosity number
|
150 / *
|
cm3/g
|
ISO 307, 1157, 1628
|
|
Rheological calculation properties
|
Value
|
Unit
|
Test Standard
|
|
Density of melt
|
1150
|
kg/m3
|
-
|
|
Thermal conductivity of melt
|
0.21
|
W/(m K)
|
-
|
|
Spec. heat capacity melt
|
2090
|
J/(kg K)
|
-
|
|
Ejection temperature
|
210
|
°C
|
-
|
...
